Dio-BSVI
With a sportier look and aggressive design, it’s time to express your attitude in the streets. DIO your sporty side, DIO some thrills and then, ‘Keep Dio’ing it’
KEEP Dio’ING IT.
Variant | Ex-Showroom Price |
DIO STD | ₹ 74629/- |
DIO DLX | ₹ 79080/- |
DIO SMART | ₹ 82580/- |
* Prices are subject to change without any prior notice.
Specifications
Body Dimensions
Length | 1808mm |
Width | 723mm |
Height | 1150mm |
Wheel Base | 1260mm |
Ground Clearance | 160mm |
Seat Length | 650mm |
Kerb Weight | 105KG |
Fuel Tank Capacity | 5.3L |
Tyres & Brakes
Tyre Size (Front) | 90/90-12 54J |
Tyre Size (Rear) | 90/100-10 53J |
Tyre Type (Front) | Tubeless |
Tyre Type (Rear) | Tubeless |
Brake Type & Size (Front) | Disc 130mm |
Brake Type & Size (Rear) | Drum 130mm |
Engine
Type | Fan Cooled, 4 Stroke, SI Engine |
Displacement | 109.51cc |
Max Net Power | 5.71 kW @ 8000 rpm |
Max Net Torque | 9 Nm @ 4750 rpm |
Bore | 47.0mm |
Stroke | 63.1mm |
Fuel System | PGM-Fi |
Compression Ratio | 10.0±0.2 |
Air Filter Type | Viscous paper filter |
Starting Method | Kick/Self |
TRANSMISSION
Clutch Type | Automatic |
FRAME & SUSPENSION
Frame Type | Under Bone |
Front | Telescopic Suspension |
Rear | 3-Step Adjustable, Spring Loaded Hydraulic |
ELECTRICALS
Battery | 3 Ah |
Headlamp | LED |
*The technical specifications and design of the vehicle may vary according to the requirements and conditions without any notice:
- Dio meets Bharat Stage VI norms.
- Product shown in the picture may vary from actual product available in the market.
- Accessories shown in the picture are not part of standard equipment.
- The technical specifications mentioned are for Deluxe variant
Colours
Standard Version
STANDARD VARIANT
STANDARD VARIANT
STANDARD VARIANT
Deluxe Version
DELUXE VARIANT
DELUXE VARIANT
DELUXE VARIANT
H-Smart Version
H-SMART VARIANT
H-SMART VARIANT
H-SMART VARIANT
Features
![Planet Honda - NEW FIERCE LED HEADLAMP*](http://palacehonda.com/wp-content/uploads/slider2/dio-bs6-newfierce_ledheadlamp.png)
For those swanky riders of the dark, the ultra stylish LED gives you a clear view of the road.
![Planet Honda - NEW DESIGNED POSITION LAMP](http://palacehonda.com/wp-content/uploads/slider2/dio-bs6-newdesigned_positionlamp.png)
The signature LED position lamp delivers a dashing look to the ride and adds a dash of style on the rider.
![Planet Honda - TELESCOPIC SUSPENSION](http://palacehonda.com/wp-content/uploads/slider2/dio-bs6-telescopic_suspension.png)
The new DIO is equipped with a Telescopic Suspension for less shock and more awe while riding. Its bigger front wheel helps to negotiate with the nastiest potholes while providing a better road grip & excellent handling conditions.
![Planet Honda - NEW FULLY DIGITAL METER](http://palacehonda.com/wp-content/uploads/slider2/dio-bs6-newfully_digitalmeter.png)
Get precise measures from real-time mileage to average mileage. Track updates about ‘distance to empty’ on the go.
![Planet Honda - EXTERNAL FUEL LID](http://palacehonda.com/wp-content/uploads/slider2/dio-bs6-external_fuellid.png)
No more hassles of lifting your seat. Take a stand for refuelling, without having to leave your seat.
![Planet Honda - ENGINE START/STOP SWITCH](http://palacehonda.com/wp-content/uploads/slider2/dio-bs6-engine_startstop_switch.png)
Switch to the better way of riding. Start and stop the engine with just a click.
![Planet Honda - Dio-BS6-Side_stand_with_inhibitor](http://palacehonda.com/wp-content/uploads/slider2/dio-bs6-side_stand_with_inhibitor.png)
A revolutionary system that cuts off the engine when the side stand is engaged.
^Available as optional
![Planet Honda - Dio BS6 Silentstart_withacg](http://palacehonda.com/wp-content/uploads/slider2/dio-bs6-silentstart_withacg.png)
The ACG starter in your Honda DIO removes gear meshing for a start as silent as a wild cat on the hunt. It also helps to reduce engine maintenance.
![Planet Honda - Dio BS6 esp_technology](http://palacehonda.com/wp-content/uploads/slider2/dio-bs6-esp_technology.png)
Get ready for one hell of a ride with the new Honda DIO. It is powered by the globally acclaimed Enhanced Smart Power Technology for a silent start, more mileage and less friction for the best riding experience.
![Planet Honda - Dio BS6 Programmedfuel_injection](http://palacehonda.com/wp-content/uploads/slider2/dio-bs6-programmedfuel_injection.png)
The sensor based PGM-FI system constantly injects optimum fuel with air which delivers an efficient combustion and results in consistent power output and more mileage.
![Planet Honda - Dio BS6 HET_BSVI_ENGINE](http://palacehonda.com/wp-content/uploads/slider2/dio-bs6-het_bsvi_engine.png)
The advanced HET engine delivers an unmatched performance and also contributes to a cleaner environment.
![Planet Honda - Dio BS6 Retractable_pillionfoot_step](http://palacehonda.com/wp-content/uploads/slider2/dio-bs6-retractable_pillionfoot_step.png)
For the ones sitting behind, the ride now becomes a ‘pillion times’ more comfortable.
![Planet Honda - Dio BS6 Passing_switch](http://palacehonda.com/wp-content/uploads/slider2/dio-bs6-passing_switch.png)
Its your ride’s way of saying ‘give me way’. Speak on the go without saying a word.
![Planet Honda - Dio BS6 Split_grab_rail](http://palacehonda.com/wp-content/uploads/slider2/dio-bs6-split_grab_rail.png)
Better grip meets gripping design. The cool and edgy looking split grab rail in the new Honda DIO makes it look like a complete stunner.
![Planet Honda - Dio BS6 stylish_muffler_protector](http://palacehonda.com/wp-content/uploads/slider2/dio-bs6-stylish_muffler_protector.png)
The stylish muffler protector in DIO makes it look really cool while protecting the feet from feeling the heat.
![Planet Honda - Dio BS6 New_frontpocket](http://palacehonda.com/wp-content/uploads/slider2/dio-bs6-new_frontpocket.png)
Store your essentials, be it your sipper or your glares. Oh goodness gracious, this front pocket is more spacious.
![Planet Honda - Dio BS6 Underseat_storage](http://palacehonda.com/wp-content/uploads/slider2/dio-bs6-underseat_storage.png)
Lift your seat upright and you have a place to perfectly store your stuff. Be it your headphone, notebook or DSLR, put it in and ride wherever.
